Insulation Material | PPO |
Contact Material | Copper,Tin plated |
Suitable Current | 30A |
Rated Voltage | 1000V (TUV) 600V (UL) |
Test Voltage | 6KV(TUV50H 1min) |
Contact Resistance | <0.5mΩ |
Degree Of Protection | IP67 |
Ambient Temperature Range | -40℃〜+85C |
Flame Class | UL 94-VO |
Safety Class | Ⅱ |
Pin Dimensions | Φ04mm |
"Discover Different Types of PV Connectors for Your Solar System - Learn About Interminability Standards and Code Compliance"Are you aware of the multiple options available for PV connectors? PV connectors are essential in linking solar modules and forming a DC home-run to the inverter. However, it's necessary to ensure that the PV connectors used in your system are UL rated for interminability for code compliance. In recent years, many module manufacturers have shifted to generic PV connectors, which differ from common brands like Staubli MC4 and Amphenol. This poses a challenge for contractors as the connectors may not have a UL rated connection. PV connectors make and model is commonly listed on module data sheets. If you see “MC4 compatible” then you are most likely dealing with a generic connector.
