Insulation Material | PPO |
Contact Material | Copper,Tin plated |
Suitable Current | 50A |
Rated Voltage | 1000V (TUV) 600V (UL) |
Test Voltage | 6KV(TUV50H 1min) |
Contact Resistance | <0.5mΩ |
Degree Of Protection | IP67 |
Ambient Temperature Range | -40℃〜+85C |
Flame Class | UL 94-VO |
Safety Class | Ⅱ |
Pin Dimensions | Φ04mm |
-What are solar panel and photovoltaic connectors and how are they used in solar energy systems?
Solar panel and photovoltaic connectors are devices used to connect solar panels or photovoltaic systems to a power source or load. They provide a secure and reliable electrical connection between components in solar energy systems, allowing for efficient energy generation and distribution.
-What types of connectors are available for solar panels and photovoltaic systems?
There are several types of connectors available for solar panels and photovoltaic systems, including MC4 connectors, Tyco connectors, and Amphenol connectors. The type of connector needed will depend on the specific system and components being used.
-How do I choose the right connector for my solar panel or photovoltaic system?
To choose the right connector for a solar panel or photovoltaic system, it is important to consider factors such as the system voltage and current, the type and size of the conductors being connected, and the environmental conditions the connectors will be exposed to. Consulting with a professional or referring to the system documentation can also be helpful.
-What are the benefits of using high-quality and advanced connectors in solar energy systems?
Using high-quality and advanced connectors in solar energy systems can lead to improved performance and reliability, as well as increased efficiency and safety. These connectors are often designed to withstand harsh environmental conditions and provide secure and durable electrical connections.
